FILTER PUMP

• CLEAN BASKET SO AS TO NEVER ALLOW WATER FLOW TO BE RESTRICTED


• RESTRICTED OR NO WATER FLOW WILL RESULT IN A BURNED OUT MOTOR, NOT COVERED UNDER WARRANTY


• APPLY WATER PROOF POOL LUBE TO O-RING AS NEEDED


HEATER

• CALL AND HAVE YOUR GAS SERVER CHECK METER SIZE, IT MAY BE TOO SMALL


• CLEAN ALL WIRES OFF HEATER


• MAINTAIN PROPER CLEARANCES OF FLAMMABLE MATERIALS


• IT IS ADVISABLE MAINTAIN A WASP TRAP WITHIN 8FT OF HEATER


AUTO FILL

• OFTEN TIMES TAKES SEVERAL ADJUSTMENTS TO GET CORRECT LEVEL


• DO NOT USE TO AID IN FILLING POOL, THE WATER WILL MARK FRESH PLASTER


• THIS UNIT IS SIMILAR TO A COMMON TOILET FLOAT


• SHUT OFF IS AN ANTI SIPHON VALVE AT OR NEAR HOSE FAUCET


• MINOR ADJUSTMENT: squeeze clip on slide bar, slide float up or down


• MAJOR ADJUSTMENT: shut valve off, slide shaft ring down, pull up float assembly till clicks on seat, slide keeper ring back in place. Turn water back on and make sure not running continuous


• REQUIRES A BASIN WRENCH TO REMOVE AND CHECK MAIN SCREEN AT BOTTOM


• ONLY DEBRIS AND INSECTS CAN CAUSE THE FLOAT TO STICK


• IF FLOAT IS STUCK, SHUT OFF AND CALL YOUR BUILDER, INSECTS ARE NOT COVERED UNDER WARRANTY


• IF YOU HAVE A WELL OR OLD PLUMBING, THEN DEBRIS MAY CLOG THE AUTO FILL, YOU SHOULD INSTALL AN IN-LINE  FILTER


• THE POOL MAY LOSE UP TO 1/2:” WATER PER DAY IN THE SUMMER


SKIMMER

• THE SKIMMER IS THE LOCATION OF SUCTION FROM TOP AND BOTTOM


• FLAPPER WEIR SKIMS DEBRIS OFF TOP


• IF YOU HAVE A SUCTION POOL CLEANER, SHUTTING OFF VALVE TO IT WILL INCREASE SUCTION TO SKIMMER, OR DECREASE SUCTION WHEN TURNED MORE TOWARD THE CLEANER


• BASKET INSIDE SKIMMER MUST BE CLEANED AS NEEDED


• IF BASKET FLOATS, PLACE 2” ROUND ROCK IN BASKET TO HOLD IT DOWN


• WEIRS ONLY BREAK FROM LARGE WAVES CAUSED BY CANNON BALL TYPE SPLASHES, NOT A WARRANTY ITEM


• FLOAT (UNDER THE SKIMMER BASKET) OR TAB ADJUSTMENT WILL INCREASE FLOW FROM MAIN DRAIN


RETURN LINE FITTINGS

• THE FITTINGS ON THE SIDE WALL OF THE POOL WHERE WATER RETURNS MAY BE ADJUSTED BY MOVING THE DIRECTIONAL EYEBALL FITTING IN THE DESIRED DIRECTION


• WATER FLOW MAY BE REDUCED WHEN WATER FLOW IS DIVERTED TO A WATER FEATURE


• DIRECTIONAL WATER FLOW CAN PUSH THE POOL SWEEP HOSES CAUSING IT NOT TO WORK ADJUST THE WATER RETURNS DOWN AND AWAY FROM THE HOSES
