CARTRIDGE FILTERS

• MUST BE CLEANED 3 TIMES IN THE FIRST MONTH WITH NEW PLASTER


• MUST BE CLEANED AFTER 1ST MONTH CLEAN AFTER PRESSURE RAISES 5 LBS ABOVE CLEAN RUNNING PRESSURE, OR EVERY 3 MONTHS, WHICHEVER COMES FIRST


• SUN TAN LOTIONS, BODY OILS, DEODORANTS, ECT.. ARE ALL BAD FOR FILTERS, SHOWER PRIOR TO SWIMMING WHENEVER POSSIBLE


• PURCHASE NEW FILTERS WHEN CLEANING NO LONGER REDUCES THE RUNNING PRESSURE


TO CLEAN FILTERS:

• SHUT OFF PUMP, MAKE SURE THAT THE TIMER IS NOT SET TO COME ON DURING THE TIME OF YOUR CLEANING PROCESS


• OPEN LID ON FILTER PUMP


• RELIVE PRESSURE ON TOP OF FILTER (AIR RELIEF)


• USE CRESCENT WRENCH TO COMPLETELY LOOSEN NUT ON BAND


• REMOVE BAND, CAUTION NOT TO LOSE NUT, SPRING AND RETAINER WASHER PARTS


• LIFT TOP OF TANK, SLIGHT TAP WITH PALM OF HAND ON SIDE WILL LOOSEN


• REMOVE THE BRIDGE / KEEPER FROM THE TOP OF CARTRIDGES


• REMOVE CARTRIDGES AND WASH THOROUGHLY WITH HOSE WITH PRESSURE TYPE NOZZLE


• CLEAN EXCESS HEAVY DEBRIS FROM INSIDE OF LOWER TANK


• REPLACE CARTRIDGES (BEST TO FLIP/ROTATE THE CARTRIDGES TOP TO BOTTOM)


• PLACE BRIDGE / KEEPER RETAINER ON THE TOP OF THE CARTRIDGES


• APPLY WATER PROOF GREASE LIBERALLY ON O-RING THEN PLACE TOP COVER AND BAND


• TIGHTEN BAND SLOWLY WHILE TAPPING IT WITH THE WOODEN END OF A HAMMER UNTIL NEARLY TIGHT


• PRIME MOTOR BASKET HOUSING WITH WATER IF EQUIPMENT MORE THAN 15” ABOVE POOL WATER


• SCREW DOWN LID ON MOTOR


• TURN ON PUMP


• LET PUMP PRIME AND RUN


• OPEN THE  AIR RELIEF VALVE ON TOP OF THE FILTER UNTIL YOU SEE WATER ONLY, THEN CLOSE RELIEF


NOTE PRESSURE AND POSITION OF ALL VALVES (A CHANGE IN VALVE POSITION WILL CHANGE PRESSURE)

SAND FILTERS

• BACK WASH 3 TIMES IN FIRST MONTH


• BACK WASH EVERY 3 MONTHS OR WHEN FILTER PRESSURE RISES 6-8 LBS OVER CLEAN PRESSURE


• CHANGE SAND WHEN BACK WASH NO LONGER REDUCES PRESSURE


TO BACK WASH SAND FILTERS:

• SHUT OFF FILTER PUMP MOTOR


• ROLL OUT BACK HOSE, MAKE SURE NO KINKS


• MOVE HANDLE TO BACK WASH POSITION


• TURN FILTER PUMP MOTOR ON AND BACK WASH FOR APPROX 2 TO 3 MINUTES


• SHUT FILTER OFF


• MOVE BACK WASH VALVE TO RINSE (IF 6-WAY VALVE)


• TURN FILTER PUMP MOTOR ON AND RUN FOR 10 SECONDS


• TURN FILTER PUMP MOTOR OFF AND MOVE VALVE BACK TO FILTER POSITION


• TURN PUMP BACK ON
